Architectural and Engineering Glossary

A
A

1.Abbr. for ampere, a unit of electric current.  2.Abbr. for area


A-block

A hollow, concrete masonry unit with one end closed and the opposite end open, havinga web between, so that two cells are formed when the block is laid in a wall.

A-weighted Sound Level

The sound level measured with a sound-level meter using A weighting,which alters the sensitivity of the sound- level meter with respect to frequency so that the sound level meter is less sensitive at frequencies where the ear is less sensitive;usually used in       specifying permissible sound levels in buildings.

A.d.

Abbr. for “air dried.”

A/W

Abbr.for “all-weather.”

AA

Abbr. for the “Architectural Association,” the largest school of architecture in England.

Aaron’s Rod

 An ornament or molding consisting of a straight rod from which pointed leaves or scroll work emerge on either side, at regular intervals.

ABA

Abbr. for Architectural Barriers Act.

Abaciscus

1. A tessera, as used in mosaic work. Also called abaculus. 2. A small abacus.


Abacus

The uppermost member of the capital of a column; often a plain square slab, but sometimes molded or otherwise enriched.

Abamurus

A buttress, or a second wall added to strengthen another.

Abat-sons

Descriptive of a surface said to reflect sound downward.

Abate

1.To remove material, as in stone carving.2.In metalwork, to cut away or beat down  so as to show a pattern or figure in low relief.

Abated

Said of a surface that has been cut away or beaten down so as to show a pattern or figure in low relief; also see relief.


Abatement

 The wastage of wood when lumber is sawed or planed to size

Abatjour

1.In a wall, an aperture whose sides have been cut back and/or whose underside has been sloped downward so as to admit a greater amount of light to the interior of the room. 2.A skylight.

Abaton

A sanctuary not to be entered by the public; a holy of holies.

Abatvent

1.Louvers that are placed in an exterior wall opening to permit light and air to enter,but break the wind.2.A sloping roof.3.In the French Vernacular architecture of New Orleans,an extension of a roof over a sidewalk.

Abatvoix

In a church, a sound reflector behind and over a pulpit.

Abbey

A monastery or convent; particularly the church thereof.

Abbreuvoir

Same as abreuvoir.ABC 1.Abbr. for “aggregate base course.” 2.Abbr. for “Associated Builders and Contractors.”


Abney Level

 A hand level used for measuring vertical angles; comprised of a small telescope, bubble tube, and graduated vertical arc.

Above-grade Building Volume

The volume of a building (in cubic feet or in cubic meters) measured from the average adjoining grade level to the average roof level, and from outside to outside of exterior walls, but not including breezeways, porches, or terraces.

Abrade

To wear away or scrape off a surface, especially by friction.

Abrams’ Law

A statement applying to given concrete materials and conditions of test: For a mixture of workable consistency, the strength of concrete provided by the mixture is determined by the ratio of the amount of water to the amount of cement.

Abrasion

 A surface discontinuity caused by roughening or scratching.

Abrasion Resistance

The ability of a surface to resist being worn away or to maintain its orig- inal appearance when rubbed with another object.

Abrasion Resistance Index

 A measure of the abrasion resistance of a vulcanized material or synthetic rubber  compound  relative  to  that  of  a standard rubber compound under specified conditions.

Abrasive

 A hard substance for removing mate- rial by grinding, lapping, honing, and polish- ing. Common abrasives include silicon carbide, boron carbide, diamond, emery, garnet, quartz, tripoli, pumice, diatomite, metal shot, grit, and various sands; usually adhered to paper or cloth.

Abraum

 A red ocher used to stain mahogany.

Abreuvoir

 In masonry, a joint or interstice between stones, to be filled with mortar or cement.

ABS

Abbr. for acrylonitrile-butadiene-styrene.

ABS Plastic

 A plastic of acrylonitrile-butadiene- styrene; has good resistance to impact, heat, and chemicals; esp. used for piping.

Abscissa

In the plane Cartesian coordinate sys- tem, the horizontal coordinate of a point on a plane; the x-coordinate, obtained by measuring the distance from the point to the y-axis along a line parallel to the x-axis.

Absolute Humidity

The mass of water vapor per unit volume of air.

Absolute Pressure

 The sum of the gauge pressure plus atmospheric pressure.

Absolute Volume

1.Of a granular material, the total volume of the particles, including the permeable and impermeable voids, but excluding the spaces between the particles. 2.Of fluid, the volume which the fluid occupies. 3.The displacement volume of an ingredient of concrete or mortar.

Absorbed Moisture

 Moisture that has entered a solid material by absorption and has physical properties not substantially different from ordinary water at the same temperature and pressure. Also see absorption.

Absorbency

The property of a material that measures its capacity to soak up liquids.

Absorbent

 A material which, owing to an affinity for certain substances, extracts one or more such substances from a liquid or gas with which it is in contact, and which changes physically or chemically, or both, during the process.

Absorber

1.A device containing liquid for absorbing refrigerant vapor  or other  vapors. 2.In an absorption system, that part of the low pressure side of the system which is used for absorbing refrigerant vapor. 3.That part of a solar collector whose primary function is to absorb radiant solar energy.

Absorbing Well, Dry Well, Waste Well

A well used for draining off surface water and conducting it underground, where it is absorbed.

Absorptance

 In illumination engineering, the ratio of the absorbed flux to the incident flux.

Absorption

1.The process by which a liquid, or a mixture of gases and liquid, is drawn into and tends to fill permeable pores in a porous solid material; usually accompanied by a physical change, chemical change, or both,  of the  material. 2.The increase in weight of a porous solid body resulting from the penetration of liquid into its permeable pores.3.The increase in weight of a brick or tile unit when immersed in either cold or boiling water for a stated length of time; expressed as a percentage of the weight of the dry unit. 4.The process by which radiant energy, which is incident on a surface, is converted to other forms of energy.

Absorption Bed

 A pit of relatively large dimensions which is filled with coarse aggregate and contains a distribution pipe system; used to absorb the effluent of a septic tank.

Absorption Field, Disposal Field

 A system of trenches containing coarse aggregate and distribution pipes through which septic tank effluent may seep into the surrounding soil.

Absorption Rate,initial Rate Of Absorption

The weight of water absorbed when a brick is partially immersed for one minute; usually expressed in grams per minute or ounces per minute.

Absorption System

A refrigeration system in which the refrigerant gas evolved in the evaporator is taken up in an absorber and (upon the application of heat) released in a generator.

Absorption Trench

 A trench containing coarse aggregate and a distribution tile pipe through which septic-tank effluent may flow, covered with earth.

Absorption-type Liquid Chiller

 Equipment utilizing a generator, condenser, absorber, evaporator, pumps, controls, and accessories to cool water, or other secondary liquid, using absorption techniques.
